TECHNICAL DATA

TYPE	Power		Ampere	uF	R.P.M	Q.Max (L/Min)	H.Max (M)	S.Head (M)	TEMP MAX. (WATER)	TEMP MAX. (ENVIRONMENT)	N.W (kg)	DIMENSION & GW
	HP	KW	220V-1 50HZ									L	W	H	Kg
1DK14	0.50	0.33	1.8	12	2850	65	14	8	80¡æ	40¡æ	7.8	290	145	190	8.3
1.5DK18	0.75	0.55	3.7	16	2850	100	18	8	80¡æ	40¡æ	11	310	175	210	11.8
1.5DK20	1	0.75	4.6	20	2850	240	20	8	80¡æ	40¡æ	12.2	310	175	210	13
