MODEL |
1004G |
1004TG |
|
NO. OF CYLINDERS |
4 |
|
ASPIRATION |
N.A |
TC |
|
COOLING SYSTEM |
COOLING WATER |
|
Cubic capacity (L) |
4 |
|
BORE X STROKE(MM) |
100 X 127 |
|
LUBRICATION OIL CAPACITY(L) |
8.1 |
8.5 |
|
COOLING WATER CAPACITY
(INCL. RADIATOR)(L) |
21 |
22.2 |
|
DRY WEIGHT(KG) |
420 |
434 |
|
GROSS WEIGHT(KG) |
447 |
462 |
|
LENGTH(MM) |
1198 |
1242 |
|
WIDTH(MM) |
628 |
647 |
|
HEIGHT(MM) |
962 |
960 |
|
STAND-BY POWER/SPEED
(KW/1500RPM;KW/1800RPM) |
46.2/52 |
72.3/83 |
|
PRIME POWER/SPEED
(KW/1500RPM;KW/1800RPM) |
42/47 |
65.7/75 |
|
GENERATOR POWER(KW)
PRIME/STAND-BY(1800RPM) |
42/46 |
67/75 |
|
GENERATOR POWER(KW)
PRIME/STAND-BY(1500RPM) |
36/40 |
56/61 |
|
FUEL CONSUMPTION(G/KW.H) |
≤208 |
|
INTAKE AIR CAPACITY(M3/MIN) |
2.64 |
4.52 |
|
EXH. GAS CAPACITY(M3/MIN) |
7.54 |
13.1 |
|
EXHAUST GAS TEMPERATURE(℃) |
PRIME |
600 |
561 |
|
STAND-BY |
680 |
596 |
|
GOVERNOR |
MACHANICAL |
≤5﹪ |
|
ELECTRICAL |
≤1﹪ |
|
RADIATION SQUARE(M2) |
19.7 |
26.94 |
