Standard Specification
Mode
FP60-1
Outlet/inlet dia.(inch)
2x1+1.5/1.5 (inch)
Max.capacity(L/min)
250
Max.head(m)
110
Suction head(m)
3
ENGINE
168F-2
Type
4-stroke, single cylinder gasoline engine
Displacement (ml)
196
Max.output (hp/rpm)
6.5hp/3600rpm
Start mode
Recoil and hand-operated
Fuel tank capacity (L)
3.6
Fuel continuous time (hr)
2.5
UNIT
Dimensions (LxWxH)(mm)
460x370x400
Dry weight (kg)
23
