POWER BY HONDA

  Standard Specification

MODEL		GPSL8000		GPSL10000		GPSL12000
ALTERNATOR	Type	Single phase alternator
	Frequency HZ	50	60	50	60	50	60
	Cont.output KW	7.3	8.0	9.0	10.0	11.0	12.0
	Max .output KW	8.0	9.0	10.0	11.0	12.0	13.5
	Voltage regulator	220¡«240;110¡«120;220¡«240/110¡«120
	DC output	12V  20A
	Power factor	1.0
	Excitation system	Self-excitation
ENGINE	Model	GX620DG3(E)
	Type	Air-cooled 4-stroke OHV90º degrees V-Twin; Horizontal shaft
	Displacement cc.	614
	Bore x stroke mm	77X66
	Cont. output  hp	16.3			17.9
	Max. output   hp	17.9			20.0
	Ignition system	Transistor magneto(T.C.I)
	Starting system	Recoil or Electric
	Starting battery	28Ah/12V
	Compression Ratio	8.3:1
	Lube oil capacity  L	1.9
SET	Fuel tank capacity L	25
	Cont.working time h	8.0		7.5		7.0
	Dimensions (LXWXH)   mm	1100X570X720		1100X570X720		1100X570X720
	Net Weight   kg	193		198		203
	Dry Weight   kg	213		208		213
Noise level (7M)dB(A)		70		72		74
