-4 Models: Equipped with electric starter, large-capacity fuel tanks, convenient control panels and noise-damping mufflers.

Standard Specification



Model		3GF-1			3GF-3
Main Types		R	S	L	R	S	L
Generator	AC Frequency (HZ)	50	60	60	50	60	60
	AC Output Voltage	220	220	120	220	220	120
	Rated AC Output (KVA)	2.5	2.7	2.7	2.5	2.7	2.7
	Maximum AC Output (KVA)	2.8	3.0	3.0	2.8	3.0	3.0
Engine	Model	168F-2
	Type	Forced air-cooled 4-stroke OHV single-cylinder
	Displacement	196cm3
	Ignition System	Transistorized magneto
	Starting System	Recoil
	Maximum Power Output	6.5PS (4.8KW) 3600RPM
	Fuel Tank capacity (liters)	3.7			15
	Continuous Operating Hours (hr)	2.6	2.2		7.8	6.2
	Operating Noise Lever (7m) dB (A)	67	70		65	69
Dimensions	Dimensions (L x W x H) (mm)	645 x 485 x 480
	Dry weight (kg)	36			45
Standard Features	Automatic Voltage Regulator (AVR)	●
	Voltmeter	－			●
	AC Circuit Breaker	●
	Oil Alert	●
	Large-capacity Air cleaner	●
	Large-capacity Fuel Tank	－			●
	Large-capacity Muffler	●
	Accessory AC Plug	●
	Electric Starter	－
	Battery Tray Kit	－
	4-wheel Dolly Kit	－
