Condition of usage:
1.The depth for the electrical pump below the water is no more than 5m;
2.The temperature of the water is no higher of 40ºC;
3.The PH figure of the water is between 6.5¡«8.5
4.The grain diameter of the solids in the water is no bigger than 0.2mm
TECHNICAL DATA
|
Model |
Power
(KW) |
Discharge (mm) |
Vol.Freq.(V/Hz) |
Max .flow
(m3/h) |
Max.Head(m) |
Weight
(kg) |
Paciking
(cm) |
|
SPP-250F |
0.25 |
25 |
220/50 |
7.2 |
7.0 |
3.7 |
27.0¡Á19.5¡Á19.5 |
|
SPP-370F |
0.37 |
32 |
8.5 |
8.0 |
5.3 |
29.0¡Á19.5¡Á19.5 |
|
