OHV-4 stroke SP engines deliver strong, efficient generator power while consuming nearly 30% less fuel than comparable side-valve engines. Brushless Design Alternator        Large-capacity Fuel Tanks Easy, Reliable Starting                  Large-capacity Air cleaners Oil Alert System                            Large-capacity “silent” Mufflers  with guards Easy-to-use AC Circuit Breakers    Convenient Full Frame and Voltmeters

-1 Models: Simply designed, economic and practical wherever reliable electrical power is needed.

-2 Models: Equipped with large-capacity fuel tanks for long hours of uninterrupted electrical power.

-3 Models: Equipped with large-capacity fuel tanks, convenient control panels and noise-damping mufflers.

-4 Models: Equipped with electric starter, large-capacity fuel tanks, convenient control panels and noise-damping mufflers.

Standard Specification



Model		4GF-3				5GF-3
Main Types		R	S	L	LD	R	S	L	LD
Generator	AC Frequency (HZ)	50	60	60	60	50	60	60	60
	AC Output Voltage	220	220	120	120/240	220	220	120	120/240
	Rated AC Output (KVA)	3.1	3.5	3.5	1.75x2/3.3	4.0	4.5	4.5	2.25x2/4.5
	Maximum AC Output (KVA)	3.5	4.0	4.0	2.0x2/4.0	4.5	5.0	5.0	2.5x2/5.0
Engine	Model	177F				182F
	Type	Forced air-cooled 4-stroke OHV single-cylinder
	Displacement	270cm3				337cm3
	Ignition System	Transistorized magneto
	Starting System	Recoil
	Maximum Power Output	9PS (6.6KW) 3600RPM				11PS (8.1KW) 3600RPM
	Fuel Tank capacity (liters)	25
	Continuous Operating Hours (hr)	12	10			10	8.5
	Operating Noise Lever (7m) db(A)	68	70			70	72
Dimensions	Dimensions (L x W x H) (mm)	715 x 575 x 580
	Dry weight (kg)	68				80
Standard Features	Automatic Voltage Regulator (AVR)	●
	Voltmeter	●
	AC Circuit Breaker	●
	Oil Alert	●
	Large-capacity Air cleaner	●
	Large-capacity Fuel Tank	●
	Large-capacity Muffler	●
	Accessory AC Plug	●
	Electric Starter	－
	Battery Tray Kit	－
	4-wheel Dolly Kit	Optional
