DC Welding

Output way

1

Engine

Model no

F3L912

Rated welding current (A)

500

Type

Air-cooling diesel engine

Current regulation range (A)

100-550

Rated output (KW)

24

Welding rod diameter (MM)

1.5-8

Rated speed (RPM)

1500/1800

No-load voltage (V)

90

Cooling system

Air-cooling

Rated voltage (V)

25-80

Driving system

Direct coupling

Duty cycle (%)

60

Fuel

Light diesel

Rated output power (KW)

12

Lubricating system

Gear pump

Rated speed (RPM)

1500/1800

Starting system

Electric starting

Generator

Rated power (KW)

8

Battery capacity

12V-100Ah

Rated frequency (HZ)

50/60

Set

Skid mounting

Common type/Rainproof type/Trailer tpye

Rated voltage (V)

400/230

Dimension (MM)

1640×730×1050

Rated current (A)

21.65

Net weight (KG)

860

Rated power factor

0.8 Lagging

Maximum noise (AT 1m) (DB)

Soundproof type 80,other 100

Rated feature

Continuous

Tank capacity (L)

100
