Standard pecification

Model		HP-150FD	HP-200FD
PUMP	Mode	FDHP-150	FDHP-200
	Outlet/Inlet dia. (inch)	2x1''+1.5”/1.5''	2''x2''
	Max.Capacity (l/min)	300	480
	Total Head (m)	60	55
	Suction Head (m)	3	3
ENGINE	Mode	168F	168F-2
	Type	4-stroke, single cylinder gasoline engine
	Displacement (ml)	163	196
	Max.output (hp/rpm)	5.5hp/3600rpm	6.5hp/3600rpm
	Start mode	Recoil and hand-operated
	Fuel tank capacity (L)	3.6
	Fuel continuous time (hr)	3	2.5
UNIT	Dimensions (LxWxH) (mm)	520x415x430
	Dry weight (kg)	32
