  Item# QGZ500B




   TECHNICAL DATA

Type

Item

QGZ500B

QGZ500B-1

QGZ500B-2

Tillage machine

Body size(mm)

1380X650X970

Net weight/Gross weight(kg)

45/60

Tilling scope (mm)

800-1200

Tilling depth (mm)

150-300

Gear shifting

0,1,2

1

0,1,-1

Driving model

belt

Transmission oil capacity (L)

0.95

Engine

Engine model

168F-2

Borexstroke  (mmxmm)

68x54

Displacement (mL)

194

Compression Ratio

8.5:1

Max. output HP(kw)/rmp

6.5(4.8)/3600

Rated power HP(kw)/rmp

5.7(4.2)/3600

Max.Torque M.m/rmp

13.2/2500

Fuel capacity (L)

3.6

Oil capacity (L)

0.6

Fuel consumption g/KW.h

313

Air cleaner model

semi-dry; oil bath; silent; cyclone

Ignition system

Transistor  magneto

Engine Model

OHV 25deqree inclined; 1-cylinder; 4-stroke

Dimension

Package dimensions(mm)

805X755X715

20FT(set)

63

Features

With front wheel and fender

Without front wheel and fender

With front wheel and fender
